| * Key benefits - Cost effective solution - High Reliability - Robustness - Very Compact design - Prevent the movement in the wrong way - Highly customizable product |
* Main options - Fluor Elastomer Seals - Backstop - Torque range - 150 … 16,000 N |
| * Gear ratios - 5 … 33.2 |
* Transmissible Mechanical Power - Up to 226 kW |
| * Motors - Input with solid shaft - Input with e-motor coupling: > BN, BE, BX [IEC asynchronous] > BSR [IEC reluctance] > BS [IEC single phase] |
* Motor options - Thermistors and thermostat sensors - Independent forced cooling - Incremental, sin/cos absolute single/multi-turn encoders - Tropicalization - Anti-condensation heaters * Torque Range - TA 30 = 150 Nm - TA 35 = 400 Nm - TA 40 = 900 Nm - TA 45 = 1360 Nm - TA 50 = 2100 Nm - TA 60 = 3500 Nm - TA 70 = 4900 Nm - TA 80 = 6600 Nm - TA 100 = 10500 Nm - TA 125 = 16000 Nm |
