| Sprocket Size | Tooth Count | Type | Outside Diameter | Stock Bore | Recommend Max. Bore | Hub Diameter | Length Thru Bore | Weight (LBS) |
|---|---|---|---|---|---|---|---|---|
| 100C10 | 10 | C | 4.600 | 1'' | 1-7/8'' | 3-9/32 | 2-7/8'' | 6.13 |
| 100C11 | 11 | C | 5.010 | 1'' | 2-1/4'' | 3-9/16'' | 2-7/8'' | 7.12 |
| 100C12 | 12 | C | 5.420 | 1'' | 2-1/46'' | 4'' | 2-7/8'' | 8.37 |
| 100C13 | 13 | C | 5.820 | 1'' | 2-3/8'' | 3-57/64'' | 2-7/8'' | 10.00 |
| 100C14 | 14 | C | 6.230 | 1'' | 2-3/4'' | 43/16'' | 2-7/8'' | 12.19 |
| 100C54 | 54 | C | 22.210 | 1-1/2'' | 4'' | 6'' | 3-1/4'' | 78.0 |
| 100C60 | 60 | C | 24.600 | 1-1/2'' | 4'' | 6'' | 3-1/4'' | 89.0 |
| 100C70 | 70 | C | 28.580 | 1-1/2'' | 5-1/4'' | 7'' | 3-3/4'' | 125.0 |
| 100C72 | 72 | C | 29.380 | 1-1/2'' | 5-1/4'' | 7'' | 3-3/4'' | 134.0 |
| 100C76 | 76 | C | 30.973 | 1-1/2'' | 5-1/4'' | 7'' | 3-3/4'' | 143.0 |
| 100C80 | 80 | C | 32.570 | 1-1/2'' | 5-1/4'' | 7'' | 3-3/4'' | 151.0 |
| 100C84 | 84 | C | 34.160 | 1-1/2'' | 5-1/4'' | 7'' | 3-3/4'' | 170.0 |
| 100C90 | 90 | C | 36.550 | 1-1/2'' | 5-1/4'' | 7'' | 3-3/4'' | 184.0 |
| 100C96 | 96 | C | 38.930 | 1-1/2'' | 5-1/4'' | 7'' | 4-1/2'' | 203.0 |
Services we can provide
1. Produce strictly following standard dimension
2. Material: 1045 Steel / Alloy Steel / Stainless Steel 304 & 316
3. Standard: ANSI, DIN, JINS, ISO, KANA, Standard America, or customer's drawing
4. Pilot bore, finished bore, taper bore, and special bore.
5. Bright surface / high precision / Blacking /Electrophoretic-Coated
6. Advanced heat treatment and surface treatment craft
7. Best quality and competitive price.
8. Welcome OEM / ODM
9. Processing Equipment: Hobbing machine, Slotting machine, CNC lathes, and other equipment.
10. Sprocket Models: Contains special sprocket according to customer's drawings, standard sprocket (American standard and metric).
 |
 |
 |
 |
 |
 |
