| Sprocket Size | Tooth Count | Type | Outside Diameter | Stock Bore | Recommend Max. Bore | Hub Diameter | Length Thru Bore | Weight (LBS) |
|---|---|---|---|---|---|---|---|---|
| 100B8 | 8 | B | 3.770 | 1'' | 1-1/4'' | 2-7/16'' | 1-7/8'' | 2.3 |
| 100B9 | 9 | B | 4.180 | 1'' | 1-5/8'' | 2-13/16'' | 1-7/8'' | 3.2 |
| 100B10 | 10 | B | 4.600 | 1'' | 1-7/8'' | 3-1/4'' | 1-7/8'' | 4.1 |
| 100B11 | 11 | B | 5.010 | 1'' | 2-1/4'' | 3-9/16'' | 1-7/8'' | 5.3 |
| 100B12 | 12 | B | 5.420 | 1'' | 2-1/4'' | 4'' | 1-7/8'' | 6.4 |
| 100B13 | 13 | B | 5.820 | 1'' | 2-3/8'' | 3-7/8'' | 1-5/8'' | 6.6 |
| 100B14 | 14 | B | 6.230 | 1 -/4'' | 2-3/4'' | 4-3/16'' | 1-5/8'' | 7.4 |
| 100B15 | 15 | B | 6.630 | 1-1/4'' | 3'' | 4-1/2'' | 1-3/4'' | 9.2 |
| 100B16 | 16 | B | 7.030 | 1-5/16'' | 3'' | 4-1/2'' | 1-3/4'' | 9.9 |
| 100B17 | 17 | B | 7.440 | 1-5/16'' | 3'' | 4-1/2'' | 1-3/4'' | 10.8 |
| 100B18 | 18 | B | 7.840 | 1-5/16'' | 3'' | 4-1/2'' | 1-3/4'' | 11.5 |
| 100B19 | 19 | B | 8.240 | 1-5/16'' | 3'' | 4-1/2'' | 2'' | 13.1 |
| 100B20 | 20 | B | 8.620 | 1-5/16'' | 3'' | 4-1/2'' | 2'' | 14.2 |
| 100B21 | 21 | B | 9.040 | 1-5/16'' | 3'' | 4-1/2'' | 2'' | 15.3 |
| 100B22 | 22 | B | 9.440 | 1-5/16'' | 3'' | 4-1/2'' | 2'' | 16.1 |
| 100B23 | 23 | B | 9.840 | 1-1/4'' | 3'' | 4-1/2'' | 2'' | 17.2 |
| 100B24 | 24 | B | 10.250 | 1-1/4'' | 3'' | 4-1/2'' | 2'' | 19.2 |
| 100B25 | 25 | B | 10.650 | 1-1/4'' | 3'' | 4-1/2'' | 2'' | 19.5 |
| 100B26 | 26 | B | 11.050 | 1-1/4'' | 3-5/16'' | 5'' | 2'' | 21.7 |
| 100B27 | 27 | B | 11.440 | 1-1/4'' | 3-5/16'' | 5'' | 2'' | 23.0 |
| 100B28 | 28 | B | 11.840 | 1-1/4'' | 3-5/16'' | 5'' | 2'' | 24.4 |
| 100B29 | 29 | B | 12.240 | 1-1/4'' | 3-5/16'' | 5'' | 2'' | 25.0 |
| 100B30 | 30 | B | 12.640 | 1-1/4'' | 3-5/16'' | 5'' | 2'' | 26.9 |
| 100B32 | 32 | B | 13.440 | 1-1/4'' | 3-5/16'' | 5'' | 2'' | 29.8 |
| 100B35 | 35 | B | 14.640 | 1-1/4'' | 3-5/16'' | 5'' | 2-1/2'' | 36.9 |
| 100B36 | 36 | B | 15.040 | 1-1/4'' | 3-5/16'' | 5'' | 2-1/2'' | 38.6 |
| 100B38 | 38 | B | 15.840 | 1-1/4'' | 3-5/16'' | 5'' | 2-1/2'' | 41.5 |
| 100B39 | 39 | B | 16.230 | 1-1/4'' | 3-5/16'' | 5'' | 2-1/2'' | 43.6 |
| 100B40 | 40 | B | 16.630 | 1-1/4'' | 3-5/16'' | 5'' | 2-1/2'' | 46.9 |
| 100B42 | 42 | B | 17.430 | 1-1/4'' | 3-5/16'' | 5'' | 2-1/2'' | 50.4 |
| 100B45 | 45 | B | 18.630 | 1-1/2'' | 3-5/16'' | 5'' | 2-1/2'' | 54.0 |
| 100B48 | 48 | B | 19.820 | 1-1/2'' | 4'' | 6'' | 2-1/2'' | 66.0 |
Services we can provide
1. Produce strictly following standard dimension
2. Material: 1045 Steel / Alloy Steel / Stainless Steel 304 & 316
3. Standard: ANSI, DIN, JINS, ISO, KANA, Standard America, or customer's drawing
4. Pilot bore, finished bore, taper bore, and special bore.
5. Bright surface / high precision / Blacking /Electrophoretic-Coated
6. Advanced heat treatment and surface treatment craft
7. Best quality and competitive price.
8. Welcome OEM / ODM
9. Processing Equipment: Hobbing machine, Slotting machine, CNC lathes, and other equipment.
10. Sprocket Models: Contains special sprocket according to customer's drawings, standard sprocket (American standard and metric).
 |
 |
 |
 |
 |
 |
