A sprocket is a rotating mechanical wheel with teeth that engage with roller or conveyor chains to facilitate their movement in various applications and equipment. As the sprocket rotates around a central shaft, the specially designed teeth engage the gaps in the chain to pull it with a secure grip, regardless of whether it is in dirty or oily environments. Although they may resemble gears, sprockets are designed solely to work with drive chains, not other sprockets or gears.
CODE |
TYPE A | TYPE B | ||||||
| Do Outer dia. (mm) |
Dp Pitch dia. (mm) |
D Bore dia. (mm) |
Do Outer dia. (mm) |
Dp Pitch dia. (mm) |
D Bore dia. (mm) |
d Hub dia. (mm) |
H Overall length (mm) |
|
| 13T | 59 | 53.07 | 13.5 | 59 | 53.07 | 13.5 | 37 | 22 |
| 14T | 63 | 57.07 | 13.5 | 63 | 57.07 | 13.5 | 42 | 22 |
| 15T | 67 | 61.08 | 13.5 | 67 | 61.08 | 13.5 | 46 | 22 |
| 16T | 71 | 65.10 | 13.5 | 71 | 65.10 | 13.5 | 50 | 22 |
| 17T | 76 | 69.12 | 13.5 | 76 | 69.12 | 13.5 | 54 | 22 |
| 18T | 80 | 73.14 | 13.5 | 80 | 73.14 | 13.5 | 57 | 22 |
| 19T | 84 | 77.16 | 13.5 | 84 | 77.16 | 13.5 | 62 | 22 |
| 20T | 88 | 81.18 | 14 | 88 | 81.18 | 14 | 67 | 25 |
| 21T | 92 | 85.21 | 14 | 92 | 85.21 | 14 | 71 | 25 |
| 22T | 96 | 89.24 | 14 | 96 | 89.24 | 14 | 75 | 25 |
| 23T | 100 | 93.27 | 14 | 100 | 93.27 | 14 | 77 | 25 |
| 24T | 104 | 97.30 | 14 | 104 | 97.30 | 14 | 63 | 25 |
| 25T | 108 | 101.33 | 14 | 108 | 101.33 | 14 | 63 | 25 |
| 26T | 112 | 105.36 | 14 | 112 | 105.36 | 14 | 63 | 25 |
| 27T | 116 | 109.40 | 14 | 116 | 109.40 | 14 | 63 | 25 |
| 28T | 120 | 113.43 | 14 | 120 | 113.43 | 14 | 63 | 25 |
| 29T | 124 | 117.46 | 14 | 124 | 117.46 | 14 | 63 | 25 |
| 30T | 128 | 121.50 | 14 | 128 | 121.50 | 14 | 63 | 25 |
NOTE: Material: Carbon Steel / Stainless Steel (Plastic Material is Available)
Services we can provide
1. Produce strictly following standard dimension
2. Material: 1045 Steel / Alloy Steel / Stainless Steel 304 & 316
3. Standard: ANSI, DIN, JINS, ISO, KANA, Standard America, or customer's drawing
4. Pilot bore, finished bore, taper bore, and special bore.
5. Bright surface / high precision / Blacking /Electrophoretic-Coated
6. Advanced heat treatment and surface treatment craft
7. Best quality and competitive price.
8. Welcome OEM / ODM
9. Processing Equipment: Hobbing machine, Slotting machine, CNC lathes, and other equipment.
10. Sprocket Models: Contains special sprocket according to customer's drawings, standard sprocket (American standard and metric).
 |
 |
 |
 |
 |
 |
