NMRV Worm Gearbox

Raydofon Group's NMRV Worm Gearbox delivers superior power transmission with durable cast iron housing and high-efficiency worm gearing, ideal for industrial machinery and automation. Experience smooth operation, reduced noise, and extended lifespan, solving reliability issues in demanding applications. Its compact design and competitive pricing set it apart—trust Raydofon for robust performance that boosts productivity.

Send Inquiry

Product Description

Rv Series Nmrv 025-125 gearbox Aluminum Cast Iron Wheel Reduction Transmission Drive Speed Reducer Worm Gear Box

PRODUCTS CHARACTERISTICS
1. Made of high-quality aluminum alloy,light weight and non-rusting
2. Large output torque
3. Smooth in running and low in noise,can work long time in dreadful conditions.
4. High in radiating efficiency.
5. Good-looking in appearance,durable in service life and small in volume.
6. Suitable for omnibearing installation.

Features of Worm Reducer /Gearbox
1.Common mounting dimensions.
2.Aluminum and cast iron housing.
3.Worm and worm wheel transmission.
4.Compact structure and light-weight.
5.Wide range of accessories.

Benefits of Worm Gearbox / Reducer
1.Unique housing design will distinguish you from other competitors.
2.Multiple choice for oil seal.
3.The dimensions can be customized according to customer's requirements.

RV Series Nmrv 025-125 Gearbox Aluminum Cast Iron Wheel Reduction Transmission Drive Speed Reducer Worm Gear Box

Model No	NMRV025, NMRV030, NMRV040, NMRV050, NMRV063, NMRV075, NMRV090, NMRV110, NMRV130, NMRV150
Ratio	5,7.5,10,15,20,25,30,40,50,60,80,100
Material	Housing: Size 25-110 Is Aluminum Alloy, Size 110-150 Is Cast-Iron
	Worm Wheel: ZCuSn10Pb1
	Worm:20Cr
	Pinion:Tin Bronze
	Output Shaft: Steel-45#
Type	Worm Gear Speed Reducer / Gearbox / Reductor
Color	Customized Color
Packing	Carton, Honey Comb Carton, Wooden Case with Wooden Pallet
Usage	Industrial Machine, Food Stuff, Ceramics, Chemical, Packing, Dyeing, Wood Working, Glass, etc.
Flange	IEC standard flange or customized dimensions
Housing Material	Aluminum&Cast iron
Size	11 sizes(WMRV25~WMRV185)
Power	0.06~22 KW
Nominal torque	≤2548 N.m
Ratio	5~100
