| Sprocket Size | Tooth Count | Type | Outside Diameter | Stock Bore | Recommend Max. Bore | Hub Diameter | Length Thru Bore | Weight (LBS) |
|---|---|---|---|---|---|---|---|---|
| 180B11 | 11 | B | 9.010 | 1-1/2'' | 3-5/8'' | 5-1/2'' | 3'' | 29.0 |
| 180B12 | 12 | B | 9.750 | 1-1/2'' | 4'' | 6'' | 3'' | 32.0 |
| 180B13 | 13 | B | 10.480 | 1-1/2'' | 4-5/8'' | 6-3/4'' | 3-1/8'' | 40.0 |
| 180B14 | 14 | B | 11.210 | 1-1/2'' | 5-1/4'' | 7'' | 3-1/8'' | 44.0 |
| 180B15 | 15 | B | 11.930 | 1-1/2'' | 5-1/4'' | 7'' | 3-1/8'' | 48.0 |
| 180B16 | 16 | B | 12.660 | 1-1/2'' | 5-1/4'' | 7'' | 3-1/8'' | 52.0 |
| 180B17 | 17 | B | 13.390 | 1-1/2'' | 5-1/4'' | 7'' | 3-1/8'' | 58.0 |
| 180B18 | 18 | B | 14.110 | 1-1/2'' | 5-1/4'' | 7'' | 3-1/8'' | 63.0 |
| 180B19 | 19 | B | 14.830 | 1-1/2'' | 5-3/8'' | 7-1/2'' | 3-3/8'' | 74.0 |
| 180B20 | 20 | B | 15.560 | 1-1/2'' | 5-3/8'' | 7-1/2'' | 3-3/8'' | 81.0 |
| 180B21 | 21 | B | 16.280 | 1-1/2'' | 5-3/8'' | 7-1/2'' | 3-3/8'' | 83.0 |
| 180B22 | 22 | B | 17.000 | 1-1/2'' | 5-3/8'' | 7-1/2'' | 3-3/8'' | 92.0 |
| 180B23 | 23 | B | 17.720 | 1-1/2'' | 5-3/8'' | 7-1/2'' | 3-3/8'' | 99.0 |
| 180B24 | 24 | B | 18.440 | 1-1/2'' | 5-3/8'' | 7-1/2'' | 3-3/8'' | 105.0 |
| 180B25 | 25 | B | 19.160 | 1-1/2'' | 5-3/8'' | 7-1/2'' | 3-3/8'' | 113.0 |
| 180B28 | 28 | B | 21.320 | 1-1/2'' | 5-3/8'' | 8'' | 3-1/2'' | 135.0 |
Services we can provide
1. Produce strictly following standard dimension
2. Material: 1045 Steel / Alloy Steel / Stainless Steel 304 & 316
3. Standard: ANSI, DIN, JINS, ISO, KANA, Standard America, or customer's drawing
4. Pilot bore, finished bore, taper bore, and special bore.
5. Bright surface / high precision / Blacking /Electrophoretic-Coated
6. Advanced heat treatment and surface treatment craft
7. Best quality and competitive price.
8. Welcome OEM / ODM
9. Processing Equipment: Hobbing machine, Slotting machine, CNC lathes, and other equipment.
10. Sprocket Models: Contains special sprocket according to customer's drawings, standard sprocket (American standard and metric).
 |
 |
 |
 |
 |
 |
