Our in-stock standard double pitch sprockets are manufactured out of SAE-1045 case hardened steel with extra-hardened teeth and coated with black oxide. These sprockets are extremely durable, high-strength, and manufactured to high precision tolerances. Stock double pitch sprockets include standard roller and carrier roller style.
Below is a chart of all of the standard C2042 double pitch roller chain sprockets. We also stock a full line of high quality C2042 roller chain.
| Sprocket Size | Tooth Count | Outside Diameter | Stock Bore | Maximum Bore | Length Thru Bore | Weight |
|---|---|---|---|---|---|---|
|
2042A16
|
16 | 5.630" | 19/32" | -- | -- | 1.38 LBS |
|
2042A17
|
17 | 5.950" | 19/32" | -- | -- | 1.66 LBS |
|
2042A18
|
18 | 6.270" | 19/32" | -- | -- | 1.88 LBS |
|
2042A19
|
19 | 6.590" | 19/32" | -- | -- | 2.06 LBS |
|
2042A20
|
20 | 6.910" | 23/32" | -- | -- | 2.40 LBS |
|
2042A21
|
21 | 7.240" | 23/32" | -- | -- | 2.62 LBS |
|
2042A22
|
22 | 7.560" | 23/32" | -- | -- | 2.88 LBS |
|
2042A23
|
23 | 7.880" | 23/32" | -- | -- | 3.14 LBS |
|
2042A24
|
24 | 8.200" | 23/32" | -- | -- | 3.22 LBS |
|
2042A25
|
25 | 8.520" | 23/32" | -- | -- | 3.50 LBS |
|
2042A26
|
26 | 8.840" | 23/32" | -- | -- | 3.74 LBS |
|
2042A27
|
27 | -- | -- | -- | -- | -- |
|
2042A28
|
28 | 9.480" | 23/32" | -- | -- | 4.76 LBS |
|
2042A30
|
30 | 9.567" | 23/32" | -- | -- | 5.08 LBS |
|
2042B8
|
8 | 3.010" | 5/8" | 1-9/32" | 7/8" | 0.72 LBS |
|
2042B9
|
9 | 3.350" | 5/8" | 1-15/32" | 7/8" | 1.02 LBS |
|
2042B10
|
10 | 3.680" | 5/8" | 1-3/4" | 1" | 1.50 LBS |
|
2042B11
|
11 | 4.000" | 5/8" | 1-7/8" | 1" | 1.68 LBS |
|
2042B12
|
12 | 4.330" | 5/8" | 2-1/4" | 1" | 2.22 LBS |
|
2042B13
|
13 | 4.660" | 5/8" | 2-1/4" | 1" | 2.56 LBS |
|
2042B14
|
14 | 4.980" | 5/8" | 2-1/4" | 1" | 2.72 LBS |
|
2042B15
|
15 | 5.300" | 5/8" | 2-1/4" | 1" | 2.90 LBS |
|
2042B16
|
16 | 5.630" | 5/8" | 2-1/4" | 1" | 3.10 LBS |
|
2042B17
|
17 | 5.950" | 5/8" | 2-1/4" | 1" | 3.40 LBS |
|
2042B18
|
18 | 6.270" | 5/8" | 2-1/4" | 1" | 3.56 LBS |
|
2042B19
|
19 | 6.590" | 5/8" | 2-1/4" | 1" | 3.72 LBS |
|
2042B20
|
20 | 6.910" | 3/4" | 2-3/8" | 1-1/8" | 4.72 LBS |
|
2042B21
|
21 | 7.240" | 3/4" | 2-3/8" | 1-1/8" | 4.84 LBS |
|
2042B22
|
22 | 7.560" | 3/4" | 2-3/8" | 1-1/8" | 5.18 LBS |
|
2042B23
|
23 | 7.880" | 3/4" | 2-3/8" | 1-1/8" | 5.04 LBS |
|
2042B24
|
24 | 8.200" | 3/4" | 2-3/8" | 1-1/8" | 5.58 LBS |
|
2042B25
|
25 | 8.520" | 3/4" | 2-3/8" | 1-1/8" | 5.96 LBS |
|
2042B26
|
26 | 8.840" | 3/4" | 2-3/8" | 1-1/8" | 6.22 LBS |
|
2042B28
|
28 | 9.480" | 3/4" | 2-3/8" | 1-1/8" | 6.78 LBS |
|
2042B30
|
30 | 10.110" | 3/4" | 2-3/8" | 1-1/8" | 7.56 LBS |
Services we can provide
1. Produce strictly following standard dimension
2. Material: 1045 Steel / Alloy Steel / Stainless Steel 304 & 316
3. Standard: ANSI, DIN, JINS, ISO, KANA, Standard America, or customer's drawing
4. Pilot bore, finished bore, taper bore, and special bore.
5. Bright surface / high precision / Blacking /Electrophoretic-Coated
6. Advanced heat treatment and surface treatment craft
7. Best quality and competitive price.
8. Welcome OEM / ODM
9. Processing Equipment: Hobbing machine, Slotting machine, CNC lathes, and other equipment.
10. Sprocket Models: Contains special sprocket according to customer's drawings, standard sprocket (American standard and metric).
 |
 |
 |
 |
 |
 |
