R helical concentric gearbox speed reducer decelerator has the features of high versatility,good combination and heavy loading capability, along with other merits such as easy to attain various transmission ratios, high efficiency, low vibrationand high permissible axis radial load. This series can not only be combined with various kinds of reducers and variators and meet the requirements, but also beadvantage of localization of related transmission equipment.
1) Output speed: 0.6~1,028rpm
2) Output torque: up to 18,000N.m
3) Motor power: 0.18~160kW
4) Mounted form: foot-mounted and flange-mounted mounting
| Product Name | SLR Series Rigid Tooth helical reducer |
| Gear Material | 20CrMnTi |
| Case Material | HT250 |
| Shaft Material | 20CrMnTi |
| Gear Processing | Grinding finish by HOFLER Grinding Machines |
| Color | Customized |
| Noise Test | Bellow 65dB |
