| Sprocket Size | Tooth Count | Type | Outside Diameter | Stock Bore | Recommend Max. Bore | Hub Diameter | Length Thru Bore | Weight (LBS) |
|---|---|---|---|---|---|---|---|---|
| 180C30 | 30 | C | 22.760 | 1-1/2'' | 5 3/4'' | 8-1/2'' | 4-3/8'' | 180.0 |
| 180C35 | 35 | C | 26.350 | 1-1/2'' | 5 3/4'' | 8-1/2'' | 4-3/8'' | 222.0 |
| 180C40 | 40 | C | 29.940 | 1-1/2'' | 5 3/4'' | 8-1/2'' | 4-3/8'' | 270.0 |
| 180C45 | 45 | C | 33.530 | 1-1/2'' | '' | 9'' | 5'' | 315.0 |
| 180C54 | 54 | C | 39.980 | 1-1/2'' | 6'' | 9'' | 5'' | 477.0 |
| 180C60 | 60 | C | 44.280 | 1-1/2'' | 6 1/2'' | 9-1/2'' | 5-3/8'' | 489.0 |
Services we can provide
1. Produce strictly following standard dimension
2. Material: 1045 Steel / Alloy Steel / Stainless Steel 304 & 316
3. Standard: ANSI, DIN, JINS, ISO, KANA, Standard America, or customer's drawing
4. Pilot bore, finished bore, taper bore, and special bore.
5. Bright surface / high precision / Blacking /Electrophoretic-Coated
6. Advanced heat treatment and surface treatment craft
7. Best quality and competitive price.
8. Welcome OEM / ODM
9. Processing Equipment: Hobbing machine, Slotting machine, CNC lathes, and other equipment.
10. Sprocket Models: Contains special sprocket according to customer's drawings, standard sprocket (American standard and metric).
 |
 |
 |
 |
 |
 |
