LF-BQX Series Light Duty Offset Disc Harrow is designed specially for small land with steep slopes that is difficult to harrow. The disc harrow is used for breaking up the ground, shattering soil lumps and mixing crop residues into soil as green manures. This harrow is mounted to tractor by 3 point linkage, the whole straucture is enough strong to perform excellently in steep land with high speed.
| Model | LF-BQX-1.1 | LF-BQX-1.3 | LF-BQX-1.5 | LF-BQX-1.7 | LF-BQX-1.9 | LF-BQX-2.3 |
| Working width(m) | 1.1 | 1.3 | 1.5 | 1.7 | 1.9 | 2.3 |
| Working depth(mm) | 80-120 | |||||
| No.of disc(pcs) | 12 | 14 | 16 | 18 | 20 | 24 |
| Disc Diameter(mm) | 460 | 460 | 460 | 460 | 460 | 460 |
| Weight(kg) | 200 | 220 | 240 | 260 | 310 | 360 |
| Tractor power(hp) | 12-20 | 15-25 | 25-35 | 30-35 | 35-45 | 50-60 |
| Linkage | 3 point linkage Cat I | |||||
• 1. 28×28 square harrow shaft used, 200mm spacing between discs
• 2. High Carbon disc blade hardness: 38-44 HRC, assuring the toughness and wear ability of disc blade.
• 3. Compact harrow structure, convenient for assembly and adjustment
• 4. High harrowing speed and efficiency when three point mounted with tractor rear
• 5. Especially performing well in rugged land with more steep slopes
• 6. Disc harrow adopting using bearing combinations with a grease filling hole on it, keeping sand or soil from going into bearing to cause break down and maintaining conveniently
