Rated exhaust pressure
|
3.0 Mpa
|
|
Drive way
|
Secondary
direct connection |
|
cooling method
|
Air cooling
|
|
Outlet temperature
|
Ambient temperature +25 ºC |
|
Noise
|
65 dB(A)
|
|
Gas supply oil content
|
≤2 PPM
|
|
Dimensions
|
1650×1150× 1310 L×W×H(mm)
|
|
Total weight
|
868 Kg
|
|
Rated working power
|
3/380/60 PH/V/HZ
|
|
Motor protection level
|
IP54
|
|
Insulation class
|
Class F insulation
|
