Our in-stock standard double pitch sprockets are manufactured out of SAE-1045 case hardened steel with extra-hardened teeth and coated with black oxide. These sprockets are extremely durable, high-strength, and manufactured to high precision tolerances. Stock double pitch sprockets include standard roller and carrier roller style.
Below is a chart of all of the standard C2060 double pitch roller chain sprockets. We also stock a full line of high quality C2060 roller chain.
| Sprocket Size | Tooth Count | Outside Diameter | Stock Bore | Maximum Bore | Length Thru Bore | Weight |
|---|---|---|---|---|---|---|
|
2060A24
|
24 | 6.150" | 23/32" | -- | -- | 3.02 LBS |
|
2060A25
|
25 | 6.390" | 23/32" | -- | -- | 3.36 LBS |
|
2060A26
|
26 | 6.630" | 23/32" | -- | -- | 3.58 LBS |
|
2060A28
|
28 | 7.110" | 23/32" | -- | -- | 4.12 LBS |
|
2060A30
|
30 | 7.590" | 23/32" | -- | -- | 4.88 LBS |
|
2060B11
|
11 | 3.000" | 3/4" | 1" | 1-1/4" | 1.14 LBS |
|
2060B12
|
12 | 3.250" | 3/4" | 1-1/4" | 1-1/4" | 1.46 LBS |
|
2060B13
|
13 | 3.490" | 3/4" | 1-5/16" | 1-1/4" | 1.52 LBS |
|
2060B14
|
14 | 3.740" | 3/4" | 1-9/16" | 1-1/4" | 1.86 LBS |
|
2060B15
|
15 | 3.980" | 3/4" | 1-3/4" | 1-1/4" | 2.24 LBS |
|
2060B16
|
16 | 4.220" | 3/4" | 1-27/32" | 1-1/4" | 2.64 LBS |
|
2060B17
|
17 | 4.460" | 3/4" | 2-3/32" | 1-1/4" | 3.08 LBS |
|
2060B18
|
18 | 4.700" | 3/4" | 2-9/32" | 1-1/4" | 3.56 LBS |
|
2060B19
|
19 | 4.940" | 3/4" | 2-11/32" | 1-1/4" | 3.94 LBS |
|
2060B20
|
20 | 5.190" | 3/4" | 2-9/16" | 1-1/4" | 4.50 LBS |
|
2060B21
|
21 | 5.430" | 3/4" | 2-3/4" | 1-1/4" | 5.02 LBS |
|
2060B22
|
22 | 5.670" | 3/4" | 2-3/4" | 1-1/4" | 5.26 LBS |
|
2060B23
|
23 | 5.910" | 3/4" | 2-3/4" | 1-1/4" | 5.54 LBS |
|
2060B24
|
24 | 6.150" | 3/4" | 2-3/4" | 1-1/4" | 5.90 LBS |
|
2060B25
|
25 | 6.390" | 3/4" | 2-3/4" | 1-1/4" | 6.08 LBS |
|
2060B26
|
26 | 6.630" | 3/4" | 2-3/4" | 1-1/4" | 6.36 LBS |
|
2060B28
|
28 | 7.110" | 3/4" | 2-3/4" | 1-1/4" | 7.02 LBS |
|
2060B30
|
30 | 7.590" | 3/4" | 2-3/4" | 1-1/4" | 7.54 LBS |
Services we can provide
1. Produce strictly following standard dimension
2. Material: 1045 Steel / Alloy Steel / Stainless Steel 304 & 316
3. Standard: ANSI, DIN, JINS, ISO, KANA, Standard America, or customer's drawing
4. Pilot bore, finished bore, taper bore, and special bore.
5. Bright surface / high precision / Blacking /Electrophoretic-Coated
6. Advanced heat treatment and surface treatment craft
7. Best quality and competitive price.
8. Welcome OEM / ODM
9. Processing Equipment: Hobbing machine, Slotting machine, CNC lathes, and other equipment.
10. Sprocket Models: Contains special sprocket according to customer's drawings, standard sprocket (American standard and metric).
 |
 |
 |
 |
 |
 |
