| Sprocket Size | Tooth Count | Type | Outside Diameter | Stock Bore | Recommend Max. Bore | Hub Diameter | Length Thru Bore | Weight (LBS) |
|---|---|---|---|---|---|---|---|---|
| 120C11 | 11 | C | 6.010 | 1-3/8'' | 2-3/8'' | 3-9/16'' | 3-3/8'' | 12.45 |
| 120C12 | 12 | C | 6.500 | 1-3/8'' | 2-3/4'' | 4-13/16'' | 3-3/8'' | 14.80 |
| 120C13 | 13 | C | 6.990 | 1-3/8'' | 3'' | 4-5/8'' | 3-3/8'' | 17.15 |
| 120C14 | 14 | C | 7.470 | 1-3/8'' | 3-1/4'' | 4-3/4'' | 3-3/8'' | 19.50 |
| 120C40 | 40 | C | 19.960 | 1-1/2'' | 4'' | 6'' | 3-3/4'' | 92.0 |
| 120C42 | 42 | C | 20.920 | 1-1/2'' | 4'' | 6'' | 3-3/4'' | 98.0 |
| 120C45 | 45 | C | 22.350 | 1-1/2'' | 4'' | 6'' | 3-3/4'' | 99.2 |
| 120C48 | 48 | C | 23.790 | 1-1/2'' | 4'' | 6'' | 4'' | 113.0 |
| 120C54 | 54 | C | 26.650 | 1-1/2'' | 4'' | 6'' | 4'' | 133.0 |
| 120C60 | 60 | C | 29.520 | 1-1/2'' | 5-1/4'' | 7'' | 4'' | 160.0 |
| 120C70 | 70 | C | 34.300 | 1-1/2'' | 5-3/8'' | 7-1/2'' | 4-1/2'' | 206.0 |
| 120C80 | 80 | C | 39.080 | 1-1/2'' | 5-3/8'' | 7-1/2'' | 4-1/2'' | 254.0 |
Services we can provide
1. Produce strictly following standard dimension
2. Material: 1045 Steel / Alloy Steel / Stainless Steel 304 & 316
3. Standard: ANSI, DIN, JINS, ISO, KANA, Standard America, or customer's drawing
4. Pilot bore, finished bore, taper bore, and special bore.
5. Bright surface / high precision / Blacking /Electrophoretic-Coated
6. Advanced heat treatment and surface treatment craft
7. Best quality and competitive price.
8. Welcome OEM / ODM
9. Processing Equipment: Hobbing machine, Slotting machine, CNC lathes, and other equipment.
10. Sprocket Models: Contains special sprocket according to customer's drawings, standard sprocket (American standard and metric).
 |
 |
 |
 |
 |
 |
