Product Model
|
WT-SL255
|
Servo motor (optional)
|
Rotation axisβ12i HF-154;Tilt axisβ22i HF-204
|
|
Panel Size
|
Φ255mm
|
Reduction Ratio
|
Rotation axis1:120 ;Tilt axis1:180
|
|
Disk Aperture
|
Φ110mm
|
Maximum Rotation Speed Of Worktable
|
Rotation axis 25r.p.m ;Tilt axis 16.6r.p.m
|
|
Center Trough Hole
|
Φ80mm
|
Minimum Setting Angle
|
0.001°deg
|
|
Disk Height
|
300mm
|
Segmentation Accuracy
|
Rotation axis15″sec;Tilt axis30″sec
|
|
Disk T-Slot
|
12H8mm
|
Repeat Positioning Accuracy
|
Rotation axis4″sec;Tilt axis4''sec
|
|
Positioning Button
|
18H7mm
|
Locking Method
|
Rotation axis oil pressure 35Kg/cm²;Tilt axis oil pressure 35Kg/cm²
|
|
Tilt Axis Angle Range
|
-45 ~110°
|
Brake Torque
|
Rotation axis 31Kg/m ;Tilt axis 31Kg/m
|
|
Net Weight (about)
|
600Kg
|
Allowable Cutting Force
|
Rotation axis 80Kg.m ;Tilt axis 80Kg.m
|
|
Horizontal placement
|
150KG
|
Placement
|
100KG
|
